VD-N Gas wax melter box (big size)
815 € without VAT and Transport
Do you have a question? Call us!
+36 20 215 0970
Gas wax melter box
Efficiently extract wax from old or damaged frames with the Frame Wax Melter Box. Utilizing steam (boiling water) for melting, this stainless steel device handles up to 18 Dadant 435×300 frames, allowing for easy processing without frame removal. Features include a large external tank, a lower drip tray, a frame storage basket, and a gas burner. The melter offers a wax extraction efficiency of 70-80% and is powered by propane-butane gas. Ideal for effective and straightforward wax processing.
| Tank size (L/W/H) | 600x430x640mm |
| Basket size (L/W/H) | 530x420x480mm |
| Overal height | 840mm |
| Height of the tap | 240mm |
| Guarantee | 2 years |
| Weight | 33kg |
Frame size
(B) height of the frame
